Tube Tester 3413-A
Triplett Electrical Instrument Co.; Bluffton (OH)
- Country
- United States of America (USA)
- Manufacturer / Brand
- Triplett Electrical Instrument Co.; Bluffton (OH)
- Year
- 1951
- Category
- Service- or Lab Equipment
- Radiomuseum.org ID
- 97759
Click on the schematic thumbnail to request the schematic as a free document.
- Wave bands
- - without
- Power type and voltage
- Alternating Current supply (AC) / 110-120 Volt
- Loudspeaker
- - - No sound reproduction output.
- Material
- Metal case
- from Radiomuseum.org
- Model: Tube Tester 3413-A - Triplett Electrical Instrument
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 15.11 x 11.2 x 6.2 inch / 384 x 284 x 157 mm
- Notes
- Speed-Roll chart.
- Price in first year of sale
- 78.00 $
- Literature/Schematics (1)
- 1951 Newark catalog Nº 51
- Author
- Model page created by Vitor Oliveira. See "Data change" for further contributors.
