Laboratory Tube Analyzer 3444
Triplett Electrical Instrument Co.; Bluffton (OH)
- Country
- United States of America (USA)
- Manufacturer / Brand
- Triplett Electrical Instrument Co.; Bluffton (OH)
- Year
- 1959
- Category
- Service- or Lab Equipment
- Radiomuseum.org ID
- 340677
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 2
- Wave bands
- - without
- Power type and voltage
- Alternating Current supply (AC) / 117 Volt
- Loudspeaker
- - - No sound reproduction output.
- Material
- Leather / canvas / plastic - over other material
- from Radiomuseum.org
- Model: Laboratory Tube Analyzer 3444 - Triplett Electrical Instrument
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 15.1875 x 7.75 x 18.8125 inch / 386 x 197 x 478 mm
- Notes
-
Gm (Mutual Conductance) tube tester, with 5 kc signal source.
- Net weight (2.2 lb = 1 kg)
- 24 lb (24 lb 0 oz) / 10.896 kg
- Mentioned in
- -- Original-techn. papers.
- Literature/Schematics (1)
- Radio Electronics (U.S. Magazine) (May 1959, page 114, New "On the Market...Tube Analyzer Model 3444...Triplett")
- Author
- Model page created by Gottfried Silberhorn. See "Data change" for further contributors.
