Transistor Analyzer 3490-A

• Country
• United States of America (USA)

• Manufacturer / Brand
• Triplett Electrical Instrument Co.; Bluffton (OH)

• Year
• 1965 ??

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 334002

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 117 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Leather / canvas / plastic - over other material

• from Radiomuseum.org
• Model: Transistor Analyzer 3490-A - Triplett Electrical Instrument

• Shape
• Tablemodel, with any shape - general.

• Notes

• Collector voltage up to 120 V, current up to 30 A.

• Author
• Model page created by Gottfried Silberhorn. See "Data change" for further contributors.

• Other Models

• Here you find 143 models, 136 with images and 55 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
  All listed radios etc. from Triplett Electrical Instrument Co.; Bluffton (OH)
