• Country
• United States of America (USA)

• Manufacturer / Brand
• Triplett Electrical Instrument Co.; Bluffton (OH)

• Year
• 1935

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 63657

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 1

• Valves / Tubes
• 01A

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 100-130 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Metal case

• from Radiomuseum.org
• Model: Tube Tester 1210-A - Triplett Electrical Instrument

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 8 x 6.5 x 4.5 inch / 203 x 165 x 114 mm

• Notes

• Included as a test set with model 1200-A.

• Price in first year of sale
• 33.00 $

• External source of data
• Ernst Erb

• Circuit diagram reference
• Rider's Perpetual, Volume 7 = 1936 and before

• Literature/Schematics (1)
• 1938 Radolek Catalog
