• Country
• Spain

• Manufacturer / Brand
• Triplex - Radio, José Moyá-Angeler; Madrid

• Year
• 1943 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 223953

• Number of Tubes
• 5

• Valves / Tubes
• 6A7 78 75 25L6G 25Z6G

• Main principle
• Superheterodyne (common); 2 AF stage(s)

• Wave bands
• Broadcast and Short Wave (SW).

• Power type and voltage
• AC/DC-set / 125 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 6 inch = 15.2 cm

• Material
• Wooden case

• from Radiomuseum.org
• Model: Supermodelo 55U - Triplex - Radio, José Moyá-

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 445 x 220 x 215 mm / 17.5 x 8.7 x 8.5 inch

• Notes

• Triplex Radio (José Moya Angeler), receptor modelo 55-U

• Net weight (2.2 lb = 1 kg)
• 3.8 kg / 8 lb 5.9 oz (8.37 lb)

• Author
• Model page created by Mario Berta. See "Data change" for further contributors.
