555 Export
Tungsram; Budapest (see also British T.)
- Country
- Hungary
- Manufacturer / Brand
- Tungsram; Budapest (see also British T.)
- Year
- 1935/1936
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 266077
- Number of Tubes
- 6
- Main principle
- Superheterodyne (common); ZF/IF 473,6 kHz; 7 AF stage(s); Export model
- Wave bands
- Broadcast, Long Wave and 2 x Short Wave.
- Power type and voltage
- Alternating Current supply (AC) / 105-110; 120-125; 130-135; 150-160; 210-220; 240-250 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
- Material
- Wooden case
- from Radiomuseum.org
- Model: 555 [Export] - Tungsram; Budapest see also
- Shape
- Tablemodel, high profile (upright - NOT Cathedral nor decorative).
- Dimensions (WHD)
- 420 x 500 x 280 mm / 16.5 x 19.7 x 11 inch
- Notes
-
For export to Norway. Sole distributor for Norway is Royal Radio A/S in Oslo.
Made in the Orion factory.
- Author
- Model page created by Sándor Selyem-Tóth. See "Data change" for further contributors.
