• Country
• Germany

• Manufacturer / Brand
• Uher Werke; München

• Year
• 1957–1959

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 22906

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 5

• Valves / Tubes
• ECC83 ECC81 EL95 EC92 EM71

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Details
• Tape Recorder

• Power type and voltage
• Alternating Current supply (AC) / 110-240 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

• Power out
• 3 W (unknown quality)

• from Radiomuseum.org
• Model: 495 - Uher Werke; München

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 360 x 150 x 270 mm / 14.2 x 5.9 x 10.6 inch

• Notes
• Zweispur; 4,75/9,5 cm/s. Spulen-Ø 15 cm.

• Net weight (2.2 lb = 1 kg)
• 8.5 kg / 18 lb 11.6 oz (18.722 lb)

• Price in first year of sale
• 598.00 DM

• External source of data
• Erb

• Source of data
• HdB d.Rdf-& Ferns-GrH 1957/58 / Radiokatalog Band 2, Ernst Erb
