- Country
- Germany
- Manufacturer / Brand
- Uher Werke; München
- Year
- 1964–1966
- Category
- Sound/Video Recorder and/or Player
- Radiomuseum.org ID
- 26001
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 6
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Details
- Tape Recorder
- Power type and voltage
- Alternating Current supply (AC) / 110; 130; 150; 220; 240; 250 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
- Power out
- 2 W (unknown quality)
- Material
- Wooden case
- from Radiomuseum.org
- Model: 722 - Uher Werke; München
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 390 x 180 x 355 mm / 15.4 x 7.1 x 14 inch
- Notes
- Zweispur; Bandgeschwindigkeiten 9,5/19 cm/s; Spulen-Ø 18 cm.
- Net weight (2.2 lb = 1 kg)
- 8.6 kg / 18 lb 15.1 oz (18.943 lb)
- Price in first year of sale
- 499.00 DM
- External source of data
- Erb
- Source of data
- Handbuch VDRG 1964/1965 / Radiokatalog Band 2, Ernst Erb
