• Country
• New Zealand-Aotearoa

• Manufacturer / Brand
• Ultimate (Brand), Radio Ltd. & Radio (1936) Ltd.; Auckland

• Year
• 1933

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 354979

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 5

• Valves / Tubes
• 2A7 58 57 2A5 80

• Main principle
• Superheterodyne (common); ZF/IF 171 kHz; 2 AF stage(s)

• Tuned circuits
• 6 AM circuit(s)

• Wave bands
• Broadcast only (MW).

• Power type and voltage
• Alternating Current supply (AC) / 50Hz, 230 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 6 inch = 15.2 cm

• Material
• Wooden case

• from Radiomuseum.org
• Model: Courier Treasure Chest 5V - Ultimate Brand, Radio Ltd. &

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 15.75 x 9 x 8 inch / 400 x 229 x 203 mm

• Notes

• Courier 5V Treasure Chest

  5-valve superhet chest model receiver manufactured by Radio (1936) Ltd.

  See also Ultimate 514.

• Author
• Model page created by Brian Stevens. See "Data change" for further contributors.
