• Country
• New Zealand-Aotearoa

• Manufacturer / Brand
• Ultimate-Ekco (N.Z.) Co. Ltd.; Auckland

• Year
• 1959 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 356823

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 5

• Valves / Tubes
• 6BE6 EBF89 ECL82 ECL82 EZ81

• Main principle
• Superheterodyne (common); ZF/IF 460 kHz; 2 AF stage(s)

• Tuned circuits
• 6 AM circuit(s)

• Wave bands
• Broadcast only (MW).

• Details
• Changer (Record changer)

• Power type and voltage
• Alternating Current supply (AC) / 50Hz, 230 Volt

• Loudspeaker
• 2 Loudspeakers / Ø 8 inch = 20.3 cm

• Material
• Wooden case

• from Radiomuseum.org
• Model: Ultimate Polonaise Stereophonic RDZ - Ultimate-Ekco N.Z. Co. Ltd.;

• Shape
• Console with any shape - in general

• Notes

• Ultimate Polonaise Stereophonic

  5-Valve broadcast (MW) console stereogram with Garrard 4-speed record changer and two 8" Rola 8MX speakers. £66/15/-

• Price in first year of sale
• 66.75 NZ £

• Mentioned in
• -- Original prospect or advert (Press 27 April 1960 Page 10)

• Author
• Model page created by Brian Stevens. See "Data change" for further contributors.
