- Country
- Great Britain (UK)
- Manufacturer / Brand
- Ultra Electric Ltd.; London
- Year
- 1965
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 304511
-
- alternative name: Ultra Radio and Television
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 9
- Semiconductors
- AF114 AF115 AF116 AF116 AF116 OC75 or. AC156 OC81D or. AC113 OC81 or. AC154 AC127 or. AC157
- Main principle
- Superheterodyne (common); ZF/IF 475/10700 kHz
- Wave bands
- Broadcast, Long Wave and FM or UHF.
- Power type and voltage
- Dry Batteries / PP7: 9 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Power out
- 0.3 W (unknown quality)
- Material
- Various materials
- from Radiomuseum.org
- Model: 6122 - Ultra Electric Ltd.; London
- Shape
- Portable set > 8 inch (also usable without mains)
- Notes
-
A battery portable AM/FM nine transistor radio covering the MW (190-566 metres), LW (1130-2025 metres) and VHF (87.7-101MHz) bands, and Bandspread covering the high frequency end of MW (183-216 metres). Sockets for car aerial and earphone. Released April 1965, price £15 7s 8d..
- Price in first year of sale
- 15.38 GBP
- Literature/Schematics (1)
- Trader Service Sheet (suppl. of Wireless & El. Trader, etc.) (1731 dated 26 November 1965)
- Author
- Model page created by Howard Craven. See "Data change" for further contributors.
