• Country
• Italy

• Manufacturer / Brand
• Ultravox; Milano

• Year
• 1964 ??

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 183160

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 20

• Valves / Tubes
• PCC189 PCF86 EF80 EF80 EF184 PCL84 EF80 EAA91 PCL82 PCF80 PCL85 PCF802 PL36 PY81 DY87 PY82 PY82 PC86 PC88 19BEP4

• Main principle
• Superhet with RF-stage

• Wave bands
• VHF incl. FM and/or UHF (see notes for details)

• Power type and voltage
• AC/DC-set / 220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

• from Radiomuseum.org
• Model: Tiziano 19 - Ultravox; Milano

• Notes

• Analizzando lo schema, ai morsetti di alimentazione sono inseriti i simboli sia della corrente alternata che quelli della corrente continua.

• Mentioned in
• -- Schematic (“Televisori Commerciali” E. Costa U. Hoepli editore, 1966.)

• Author
• Model page created by Alessandro De Poi. See "Data change" for further contributors.
