3202

UNBEKANNTE FIRMA D / A / CH - Siehe Anleitung unter der «Firma»

Data
Forum
Pictures
Collections

  • Year
  • 1980 ??
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 305546
    • alternative name: Unknown, Custom Built

 Technical Specifications

  • Number of Transistors
  • 5
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Broadcast (BC) and FM or UHF.
  • Power type and voltage
  • Alternating Current supply (AC) / 220 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: 3202 - UNBEKANNTE FIRMA D / A / CH -
  • Shape
  • Tablemodel, low profile (big size).
  • Dimensions (WHD)
  • 480 x 115 x 130 mm / 18.9 x 4.5 x 5.1 inch
  • Notes

  •  Input for Turntable and Tape.

    Tone control

  • Net weight (2.2 lb = 1 kg)
  • 2 kg / 4 lb 6.5 oz (4.405 lb)
  • Author
  • Model page created by Pier Antonio Aluffi. See "Data change" for further contributors.
