Stereo Car Cassette Player / High Sensitivity Tuner CZ-100V

Unisef; Tokyo

Data
Forum
Pictures
Collections

  • Year
  • 1980 ??
  • Category
  • Car Radio, perhaps also + sound player/recorder
  • Radiomuseum.org ID
  • 344008

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Broadcast (BC) and FM or UHF.
  • Details
  • Cassette-Recorder or -Player
  • Power type and voltage
  • Storage Battery for all (e.g. for car radios and amateur radios) / 12 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Power out
  • 16 W (max.)
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Stereo Car Cassette Player / High Sensitivity Tuner CZ-100V - Unisef; Tokyo
  • Shape
  • Chassis only or for «building in»
  • Dimensions (WHD)
  • 168 x 43 x 120 mm / 6.6 x 1.7 x 4.7 inch
  • Notes

  • In-Dash Type Stereo Car Cassette Player with AM/FM Radio Model Unisef CZ-100V

    Frequency Range:
    AM 530 - 1605 kHz
    FM 88 - 108 MHz

    Standard Cassette Player

    12 VDC neg. Ground



  • Net weight (2.2 lb = 1 kg)
  • 0.750 kg / 1 lb 10.4 oz (1.652 lb)
  • Author
  • Model page created by Franz Scharner. See "Data change" for further contributors.
