M531S new

Unitra Lubartów; Lubartów

Data
Forum
Pictures
Collections

  • Year
  • 1975 ?
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 350825

 Technical Specifications

  • Number of Transistors
  • 27
  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Details
  • Cassette-Recorder or -Player
  • Power type and voltage
  • Alternating Current supply (AC) / 220 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Material
  • Various materials
  • from Radiomuseum.org
  • Model: M531S [new] - Unitra Lubartów; Lubartów
  • Shape
  • Tablemodel with Push Buttons.
  • Dimensions (WHD)
  • 300 x 75 x 225 mm / 11.8 x 3 x 8.9 inch
  • Notes

  • Stereokassettenrecorder 4,76 cm/s.
    Frequenzbereich: 50-12000 Hz.
    Ausgangsleistung 2 x 6 Watt.
    Externe Lautsprecher.

    Later version of M531S after production transfer.

  • Net weight (2.2 lb = 1 kg)
  • 3.5 kg / 7 lb 11.3 oz (7.709 lb)
  • Author
  • Model page created by Wolfgang Bauer. See "Data change" for further contributors.
