- Country
- Poland
- Manufacturer / Brand
- Unitra DIORA - Radiowerk Dzierzoniow,
- Year
- 1980 ??
- Category
- Sound/Video Recorder and/or Player
- Radiomuseum.org ID
- 279075
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 1
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Details
- Rec.Player+Audio.Amp+LS
- Power type and voltage
- Alternating Current supply (AC) / 220-240 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
- Power out
- 2 W (max.)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Junior 2 - Unitra DIORA - Radiowerk
- Shape
- Tablemodel without push buttons, Mantel/Midget/Compact up to 14
- Dimensions (WHD)
- 360 x 100 x 260 mm / 14.2 x 3.9 x 10.2 inch
- Notes
-
Turntable speed: 33 1/3 and 45 rpm. Tone control, Crystal cartridge.
- Mentioned in
- -- Original-techn. papers.
- Author
- Model page created by a member from SK. See "Data change" for further contributors.
