Avus Solid State Transistor Radio W-1279
Unknown - CUSTOM BUILT: Hong Kong (HK)
- Country
- Hong Kong
- Manufacturer / Brand
- Unknown - CUSTOM BUILT: Hong Kong (HK)
- Year
- 1970 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 299634
Für Herbol als Werbegeschenk hergestellt
- Number of Transistors
- 5
- Semiconductors
- Main principle
- Superheterodyne (common); ZF/IF 455 kHz
- Tuned circuits
- 4 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Dry Batteries / 6LR61: 9 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5.8 cm = 2.3 inch
- Power out
- 0.2 W (unknown quality)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Avus Solid State Transistor Radio W-1279 - Unknown - CUSTOM BUILT: Hong
- Shape
- Very small Portable or Pocket-Set (Handheld) < 8 inch.
- Dimensions (WHD)
- 145 x 78 x 35 mm / 5.7 x 3.1 x 1.4 inch
- Notes
-
AM Taschenempfänger mit 3,5mm Ohrhöreranschluss und Kunststoff-Trageschlaufe.
Empfangsbereich:
MW: 540 - 1610kHz.
- Net weight (2.2 lb = 1 kg)
- 0.225 kg / 0 lb 7.9 oz (0.496 lb)
- Author
- Model page created by Holger Struthoff. See "Data change" for further contributors.
