• Country
• Belgium

• Manufacturer / Brand
• Unknown - CUSTOM BUILT; Belgium

• Year
• 1947 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 111686

• Number of Tubes
• 6

• Valves / Tubes
• 6K8 6K7 6B8G 6V6 6E5 6ZY5

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, Long Wave and Short Wave.

• Power type and voltage
• Alternating Current supply (AC) / 110; 130; 220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 17 cm = 6.7 inch

• Power out
• 4.5 W (unknown quality)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Happy - Unknown - CUSTOM BUILT;

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 630 x 350 x 280 mm / 24.8 x 13.8 x 11 inch

• Net weight (2.2 lb = 1 kg)
• 12.5 kg / 27 lb 8.5 oz (27.533 lb)

• Source of data
• - - Data from my own collection

• Author
• Model page created by Jozef Brughmans †. See "Data change" for further contributors.
