Browni FM-902
CBC Charles Brown (Browni, Magnon, Belair); Tokyo
- Country
- Japan
- Manufacturer / Brand
- CBC Charles Brown (Browni, Magnon, Belair); Tokyo
- Year
- 1974 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 164237
- Number of Transistors
- 9
- Semiconductors
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast, Short Wave plus FM or UHF.
- Power type and voltage
- Dry Batteries / 9 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 7 cm = 2.8 inch
- Power out
- 0.25 W (unknown quality)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Browni FM-902 - CBC Charles Brown Browni,
- Shape
- Very small Portable or Pocket-Set (Handheld) < 8 inch.
- Dimensions (WHD)
- 146 x 87 x 45 mm / 5.7 x 3.4 x 1.8 inch
- Notes
- AM/FM- 9 Transistor 2 Band Radio, Ohrhöreranschluß über 3,5 mm Klinkenbuchse
- Net weight (2.2 lb = 1 kg)
- 0.390 kg / 0 lb 13.7 oz (0.859 lb)
- Author
- Model page created by Museum Roggenhofer. See "Data change" for further contributors.
