Champion Boy's Radio
Unknown - CUSTOM BUILT: Japan
- Country
- Japan
- Manufacturer / Brand
- Unknown - CUSTOM BUILT: Japan
- Year
- 1964 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 185623
- Number of Transistors
- 2
- Main principle
- TRF with diode detector
- Tuned circuits
- 1 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Dry Batteries / 9 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 2 inch = 5.1 cm
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Champion Boy's Radio - Unknown - CUSTOM BUILT: Japan
- Shape
- Very small Portable or Pocket-Set (Handheld) < 8 inch.
- Dimensions (WHD)
- 2.5 x 4.125 x 1.25 inch / 64 x 105 x 32 mm
- Notes
- Boy's Radio that uses the case as the King or Queen radios.
- Net weight (2.2 lb = 1 kg)
- 0.5 lb (0 lb 8 oz) / 0.227 kg
- Source of data
- - - Data from my own collection
- Author
- Model page created by Tom Guest. See "Data change" for further contributors.
