Colonel TR-806
Unknown - CUSTOM BUILT: Hong Kong (HK)
- Country
- Hong Kong
- Manufacturer / Brand
- Unknown - CUSTOM BUILT: Hong Kong (HK)
- Year
- 1960 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 266886
- Number of Transistors
- 9
- Semiconductors
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast (BC) and FM or UHF.
- Power type and voltage
- Dry Batteries / UM-3: 2 x 1,5 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 6 cm = 2.4 inch
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Colonel TR-806 - Unknown - CUSTOM BUILT: Hong
- Shape
- Very small Portable or Pocket-Set (Handheld) < 8 inch.
- Dimensions (WHD)
- 70 x 130 x 35 mm / 2.8 x 5.1 x 1.4 inch
- Notes
-
AM 530 - 1630 KHz; FM 88 - 108 MHz
- Net weight (2.2 lb = 1 kg)
- 0.220 kg / 0 lb 7.8 oz (0.485 lb)
- Author
- Model page created by Museum Roggenhofer. See "Data change" for further contributors.
