Deltek - Solid State Multi Band AC-DC Radio TK-1865 - LL 28684
Unknown - CUSTOM BUILT: Japan
- Country
- Japan
- Manufacturer / Brand
- Unknown - CUSTOM BUILT: Japan
- Year
- 1970 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 259493
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Main principle
- Superheterodyne (common)
- Wave bands
- Wave Bands given in the notes.
- Power type and voltage
- Line / Batteries (any type) / 117 / UM-1: 4 x 1,5 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Power out
- 0.6 W (unknown quality)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Deltek - Solid State Multi Band AC-DC Radio TK-1865 - LL 28684 - Unknown - CUSTOM BUILT: Japan
- Shape
- Portable set > 8 inch (also usable without mains)
- Dimensions (WHD)
- 11 x 9.5 x 4.5 inch / 279 x 241 x 114 mm
- Notes
-
AM: 530 - 1.600 kHz,
MB: 1.6 - 4 MHz,
SW: 4- 12 MHz,
FM: 86 - 108 MHz,
Air & PSB: 108 - 174 MHz.
Made in Japan.
- Author
- Model page created by a member from A. See "Data change" for further contributors.
