3 Band Hi-Fi 8 Transistor

Elman Co., Ltd.; Tokyo

Data
Forum
Pictures
Collections

  • Year
  • 1965 ??
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 148793

 Technical Specifications

  • Number of Transistors
  • 8
  • Semiconductors
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Broadcast plus 2 Short Wave bands.
  • Power type and voltage
  • Dry Batteries / 3 x 1,5 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: 3 Band Hi-Fi 8 Transistor - Elman Co., Ltd.; Tokyo
  • Shape
  • Very small Portable or Pocket-Set (Handheld) < 8 inch.
  • Dimensions (WHD)
  • 8.5 x 5 x 0 inch / 216 x 127 x 0 mm
  • Notes

  • Elman Hi-Fi 8 Transistor;
    Front deep blue and chrome, reverse ivory colored, telescopic antenna, "Radicator" tuning meter, SW1: ~3 - 9 MHz, SW2: ~9 - 18 MHz, MW-AM: ~540 - 1600 KHz, dial light button, in total three jacks/terminals, one for earphones, made in Japan.

  • Author
  • Model page created by a member from A. See "Data change" for further contributors.
