2-Band 7-Transistor EP-721 MW-LW

EPEO (brand)

Data
Forum
Pictures
Collections

  • Year
  • 1965 ??
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 208679

 Technical Specifications

  • Number of Transistors
  • 7
  • Semiconductors
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Broadcast (MW) and Long Wave.
  • Power type and voltage
  • Dry Batteries / 9 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: 2-Band 7-Transistor EP-721 [MW-LW] - EPEO brand
  • Shape
  • Very small Portable or Pocket-Set (Handheld) < 8 inch.
  • Dimensions (WHD)
  • 135 x 80 x 33 mm / 5.3 x 3.1 x 1.3 inch
  • Notes

  • Epeo EP-721 2-Band 7-Transistor;
    Ferrite rod & telescopic antenna, earphones jack & DC in.

    Made in Japan.

    Similar shape to National Matsushita T45

  • Author
  • Model page created by a member from A. See "Data change" for further contributors.
