Norge CB Linear Amplifier 60
CEP Costruzioni Elettroniche Professionali; Milano
- Country
- Italy
- Manufacturer / Brand
- CEP Costruzioni Elettroniche Professionali; Milano
- Year
- 1965 ??
- Category
- Citizen Band Equipment
- Radiomuseum.org ID
- 292380
Ein Drehknopf beschädigt (Alu-Kappe fehlt)
- Number of Tubes
- 1
- Valves / Tubes
- 6JE6C
- Main principle
- Radio Frequency Amplification only
- Wave bands
- Short Wave (SW only)
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- - - No sound reproduction output.
- Material
- Metal case
- from Radiomuseum.org
- Model: Norge CB Linear Amplifier 60 - CEP Costruzioni Elettroniche
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 233 x 113 x 240 mm / 9.2 x 4.4 x 9.4 inch
- Notes
-
Verstärker zur Erhöhung der Sendeleistung von Sprechfunkgeräten im Frequenzbereich 26 - 30 MHz (10 m- und 11 m-Band).
Mit Ausnahme der etwas anders gestalteten Frontplatte ist das Gerät baugleich mit dem Modell GGS Linear Amplifier Yankee 1.
Siehe auch CEP Modell Norge 60/2 (Speisung mit 220 V AC und 12 V DC).
- Net weight (2.2 lb = 1 kg)
- 6 kg / 13 lb 3.5 oz (13.216 lb)
- Author
- Model page created by Siegfried Droese. See "Data change" for further contributors.
