Logend LG-1311

Unknown to us - Worldwide

Data
Forum
Pictures
Collections

  • Year
  • 1988 ??
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 347341

 Technical Specifications

  • Number of Transistors
  • 4
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Broadcast, 2 Short Wave plus FM or UHF.
  • Power type and voltage
  • Batteries / addl. power jack / UM1: 1 x 1.5 / DC 1.5 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 6 cm = 2.4 inch
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Logend LG-1311 - Unknown to us - Worldwide
  • Shape
  • Very small Portable or Pocket-Set (Handheld) < 8 inch.
  • Dimensions (WHD)
  • 150 x 85 x 40 mm / 5.9 x 3.3 x 1.6 inch
  • Notes

  • Pocket radio with FM - MW - SW1 - SW2 and TV channels 2-5.
    Internal ferrite antenna for AM and telescopic antenna for FM.
    Phones jack.

  • Net weight (2.2 lb = 1 kg)
  • 0.3 kg / 0 lb 10.6 oz (0.661 lb)
  • Author
  • Model page created by Pier Antonio Aluffi. See "Data change" for further contributors.
