Modutec - Multi-Tester MO-20KT

Unknown - CUSTOM BUILT: Japan

Data
Forum
Pictures
Collections

  • Year
  • 2000 ??
  • Category
  • Service- or Lab Equipment
  • Radiomuseum.org ID
  • 252632

 Technical Specifications

  • Wave bands
  • - without
  • Power type and voltage
  • Dry Batteries / 2 x 1,5 Volt
  • Loudspeaker
  • - - No sound reproduction output.
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Modutec - Multi-Tester MO-20KT - Unknown - CUSTOM BUILT: Japan
  • Shape
  • Very small Portable or Pocket-Set (Handheld) < 8 inch.
  • Dimensions (WHD)
  • 92 x 121 x 50 mm / 3.6 x 4.8 x 2 inch
  • Notes

  • Voltage ranges:
    DC 0-0,5, 2,5, 10, 50, 250, 1000 VDC; (22,2K omhs/volt);
    AC 0-10, 50, 250, 500, 1000 VAC; (10K ohms/volt);

    Current range:
    DC 0-0,05, 25, 250 mADC; (500 mVDC);

    Resistance ranges:
    R1   - 0-5 K ohms; (50 ohms mid-scale);
    R10 - 0-50 K omhs (500 ohms mid-scale);
    R100 0-500K ohms; (5k ohms mid-scale);

    Temperature range:
    -10 to + 300° F; (with external probe accessory);

    Accuracy DC:
            +/- 3% of full scale;
    AC: +/- 4% of full scale;
    Temperature: +/- 3% of full scale.

  • Net weight (2.2 lb = 1 kg)
  • 0.240 kg / 0 lb 8.5 oz (0.529 lb)
  • Author
  • Model page created by Edoardo Sigismondo. See "Data change" for further contributors.
