• Country
• Japan

• Manufacturer / Brand
• Unknown - CUSTOM BUILT: Japan

• Year
• 1963 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 182625

• Number of Transistors
• 7

• Semiconductors
• 2SA201 2SA202 2SA203 2SA203 2SB186 2SB33 2SB33

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast only (MW).

• Power type and voltage
• Dry Batteries / 2 x 1,5 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4.5 cm = 1.8 inch

• Power out
• 0.1 W (unknown quality)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Neo-Sonic 7 Transistor - Unknown - CUSTOM BUILT: Japan

• Shape
• Very small Portable or Pocket-Set (Handheld) < 8 inch.

• Dimensions (WHD)
• 62 x 98 x 25 mm / 2.4 x 3.9 x 1 inch

• Notes
• Petit transportable radio avec une sortie d’écouteur, dans un étui.

• Net weight (2.2 lb = 1 kg)
• 0.2 kg / 0 lb 7 oz (0.441 lb)

• Author
• Model page created by Bekir Yurdakul. See "Data change" for further contributors.

• Other Models

• Here you find 1139 models, 1001 with images and 97 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
