Nejva {Нейва} [Neywa] 2 (2 bands; OIRT 64-73 MHz)

• Country
• Soviet Union

• Manufacturer / Brand
• Kamensk-Uralsk Radio Works

• Year
• 1986–1989

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 181728

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Wave bands
• Broadcast (BC) and FM or UHF.

• Power type and voltage
• Storage and/or dry batteries / 9 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Nejva {Нейва} [Neywa] 2 - Kamensk-Uralsk Radio Works

• Shape
• Very small Portable or Pocket-Set (Handheld) < 8 inch.

• Dimensions (WHD)
• 97 x 151 x 41 mm / 3.8 x 5.9 x 1.6 inch

• Notes

• There are at least two Nejva {Нейва} [Neywa] models 2, one for CCIR (88-108 MHz) and the other for OIRT (64-73 MHz). 1 Ic, this model has FM: OIRT.

  The look and shape is similar to some Sanyo models (e.g. RP5040A), but the design of the circuit is completely different.

• Net weight (2.2 lb = 1 kg)
• 0.450 kg / 0 lb 15.9 oz (0.991 lb)

• Source of data
• - - Data from my own collection

• Author
• Model page created by Sándor Selyem-Tóth. See "Data change" for further contributors.
