• Country
• Soviet Union

• Manufacturer / Brand
• Unknown - CUSTOM BUILT: Soviet Union

• Year
• 1987

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 130397

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 0

• Valves / Tubes
• 6ЛО1И

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Metal case

• from Radiomuseum.org
• Model: Oscillograf {Осциллограф} OML-3M {ОМЛ-3М} - Unknown - CUSTOM BUILT: Soviet

• Shape
• Tablemodel with Push Buttons.

• Dimensions (WHD)
• 194 x 128 x 214 mm / 7.6 x 5 x 8.4 inch

• Notes

• Bandbreite im Y-Kanal 3 Hz - 5 MHz bei ± 3 dB

• Net weight (2.2 lb = 1 kg)
• 3.5 kg / 7 lb 11.3 oz (7.709 lb)

• Price in first year of sale
• 125.00 Rubel

• Source of data
• -- Original-techn. papers.

• Mentioned in
• - - Manufacturers Literature (Kontrolldatum 7.87 mit Seriennr. aus Bedienanweisung)

• Author
• Model page created by Klemens Rhode. See "Data change" for further contributors.
