Oscillograf - Осциллограф N3017 - H3017

Unknown - CUSTOM BUILT: Soviet Union

Data
Forum
Pictures
Collections

  • Year
  • 1985 ??
  • Category
  • Service- or Lab Equipment
  • Radiomuseum.org ID
  • 203283

 Technical Specifications

  • Number of Tubes
  • 1
  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Wave bands
  • - without
  • Power type and voltage
  • Line / Batteries (any type) / 220 / 42 Volt
  • Loudspeaker
  • - - No sound reproduction output.
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Oscillograf - Осциллограф N3017 - H3017 - Unknown - CUSTOM BUILT: Soviet
  • Shape
  • Tablemodel, with any shape - general.
  • Dimensions (WHD)
  • 255 x 55 x 330 mm / 10 x 2.2 x 13 inch
  • Notes
  • Oscillograph {Осциллограф} N3017 {H3017};
    Single channel, different colors known.
  • Net weight (2.2 lb = 1 kg)
  • 2.5 kg / 5 lb 8.1 oz (5.507 lb)
  • Author
  • Model page created by a member from A. See "Data change" for further contributors.
