• Country
• Japan

• Manufacturer / Brand
• Unknown - CUSTOM BUILT: Japan

• Year
• 1965 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 221984

• Number of Transistors
• 6

• Semiconductors
• 2SA52 2SA49 2SA53 2SB54 2SB56 2SB56

• Main principle
• Superheterodyne (common)

• Tuned circuits
• 5 AM circuit(s)

• Wave bands
• Broadcast only (MW).

• Power type and voltage
• Dry Batteries / 1 x 9 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5 cm = 2 inch

• Power out
• 0.1 W (unknown quality)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Play Boy 6YR-67 - Unknown - CUSTOM BUILT: Japan

• Shape
• Very small Portable or Pocket-Set (Handheld) < 8 inch.

• Dimensions (WHD)
• 65 x 93 x 25 mm / 2.6 x 3.7 x 1 inch

• Notes
• See also the similar model Brownie 6YR-67C.

• Net weight (2.2 lb = 1 kg)
• 0.120 kg / 0 lb 4.2 oz (0.264 lb)

• Author
• Model page created by José Manuel Silvestre. See "Data change" for further contributors.
