PLL Synthesizer Receiver 4 Band Logo Mercedes

Unknown to us - Worldwide

Data
Forum
Pictures
Collections

  • Year
  • 1998 ??
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 341901

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Main principle
  • PLL, Phase-locked loop
  • Wave bands
  • Broadcast, (BC) Long Wave (LW), 2 x SW and FM or UHF.
  • Power type and voltage
  • Batteries / addl. power jack / AA: 3 x 1,5 / DC: 4,5 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: PLL Synthesizer Receiver 4 Band Logo Mercedes - Unknown to us - Worldwide
  • Shape
  • Very small Portable or Pocket-Set (Handheld) < 8 inch.
  • Dimensions (WHD)
  • 180 x 120 x 38 mm / 7.1 x 4.7 x 1.5 inch
  • Notes

  • 4 Band PLL Digital Tuning Radio, with clock / alarm.

    Frequency range:
     -  FM:   87.5-108 MHz
     -  MW:  531-1602 kHz
     -  LW:   153-281 kHz
     -  SW2: 5.9-15.5 MHz.

  • Net weight (2.2 lb = 1 kg)
  • 0.435 kg / 0 lb 15.3 oz (0.958 lb)
  • Author
  • Model page created by Manfred Rathgeb. See "Data change" for further contributors.
