• Country
• Spain

• Manufacturer / Brand
• Ravim, Radio Vicente Meneu; Villareal (CP)

• Year
• 1956 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 352902

• Number of Tubes
• 5

• Valves / Tubes
• ECH81 EAF42 EBC41 EL84 EZ80

• Main principle
• Superheterodyne (common); ZF/IF 470 kHz; 2 AF stage(s)

• Wave bands
• Broadcast and Short Wave (SW).

• Power type and voltage
• Alternating Current supply (AC) / 110 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Desconocido - unknown 1 Madera, 4 mandos, rejilla plástico con olas - Ravim, Radio Vicente Meneu;

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 470 x 300 x 205 mm / 18.5 x 11.8 x 8.1 inch

• Author
• Model page created by José Branchadell. See "Data change" for further contributors.
