Royal Montreal Ch= Philips 22GC010/38
Unknown - CUSTOM BUILT: Italy
- Country
- Italy
- Manufacturer / Brand
- Unknown - CUSTOM BUILT: Italy
- Year
- 1970 ??
- Category
- Sound/Video Recorder and/or Player
- Radiomuseum.org ID
- 308249
- Number of Transistors
- 4
- Semiconductors
- AC130 unknown_tr unknown_tr unknown_tr
- Wave bands
- - without
- Details
- Rec.Player+Audio.Amp+LS
- Power type and voltage
- Line / Batteries (any type) / 125; 160; 220 / 2 x 4,5 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 9 cm = 3.5 inch
- Material
- Leather / canvas / plastic - over other material
- from Radiomuseum.org
- Model: Royal Montreal Ch= Philips 22GC010/38 - Unknown - CUSTOM BUILT: Italy
- Shape
- Portable set > 8 inch (also usable without mains)
- Dimensions (WHD)
- 390 x 95 x 230 mm / 15.4 x 3.7 x 9.1 inch
- Notes
-
Giradischi Philips 22GC010/38. 3 velocità: 33 - 45 - 78 giri. Testina 22GP306. Marchio "Royal Phone Electronic"
- Net weight (2.2 lb = 1 kg)
- 2.950 kg / 6 lb 8 oz (6.498 lb)
- Author
- Model page created by Pier Antonio Aluffi. See "Data change" for further contributors.
