FM/MW/SW 8 Band World Receiver WE-2300 DT-57341

• Country
• Germany

• Manufacturer / Brand
• SilverCrest / Silver Crest (Lidl-Marke)

• Year
• 2011 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 263778

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 7

• Semiconductors
• CXA1691 S9018 S8550 S9014 S9014 S9014 S9014 S9014

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, more than 2 SW bands plus FM or UHF.

• Power type and voltage
• Dry Batteries / AA: 2 x 1,5 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4.5 cm = 1.8 inch

• Power out
• 0.2 W (undistorted)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: FM/MW/SW 8 Band World Receiver WE-2300 DT-57341 - SilverCrest / Silver Crest

• Shape
• Very small Portable or Pocket-Set (Handheld) < 8 inch.

• Dimensions (WHD)
• 125 x 75 x 25 mm / 4.9 x 3 x 1 inch

• Notes

• Silver Crest AM-FM WE-2300 6 x SW

  Display LCD con illuminazione background per la visualizzazione digitale di frequenza ed ora (12/24 ore)
  DX/sensitivity switch-over
  Uscita cuffie - ingresso alimentatore (3V) e presa per antenna

  Import für Deutschland: Targa GmbH, Lange Wende 41, D-59494 Soest.

• Net weight (2.2 lb = 1 kg)
• 0.2 kg / 0 lb 7 oz (0.441 lb)

• Author
• Model page created by Edoardo Sigismondo. See "Data change" for further contributors.

• Other Models

• Here you find 22 models, 22 with images and 5 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
  All listed radios etc. from SilverCrest / Silver Crest (Lidl-Marke)
