Standard Broadcast (marcado en dial)
Unknown - CUSTOM BUILT: Argentina
- Country
- Argentina
- Manufacturer / Brand
- Unknown - CUSTOM BUILT: Argentina
- Year
- 1933 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 337697
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast and Short Wave (SW).
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 5 inch = 12.7 cm
- Material
- Wooden case
- from Radiomuseum.org
- Model: Standard Broadcast - Unknown - CUSTOM BUILT:
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 380 x 220 x 220 mm / 15 x 8.7 x 8.7 inch
- Notes
-
Radio armada sin marca visible.
Es el montaje de un plan de estudios por correspondencia, actualmente desconocido.
- Author
- Model page created by Dario Marujo. See "Data change" for further contributors.
