V/A and Transistor Meter TL-4M {ТЛ-4М}
Tartu Control Device Plant; Tartu
- Country
- Estonia (Eesti, Tallinn)
- Manufacturer / Brand
- Tartu Control Device Plant; Tartu
- Year
- 1978–1991
- Category
- Service- or Lab Equipment
- Radiomuseum.org ID
- 173280
Click on the schematic thumbnail to request the schematic as a free document.
- Wave bands
- - without
- Power type and voltage
- Dry Batteries / 2 × 1,5 Volt
- Loudspeaker
- - - No sound reproduction output.
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: V/A and Transistor Meter TL-4M {ТЛ-4М} - Tartu Control Device Plant;
- Shape
- Very small Portable or Pocket-Set (Handheld) < 8 inch.
- Dimensions (WHD)
- 103 x 159 x 59 mm / 4.1 x 6.3 x 2.3 inch
- Notes
- 100 mV, mikroA U: AC/DC 1; 3; 10; 30; 100; 300; 1000 V. I: DC 0,3 mA; 1 mA AC/DC 3; 30; mA 0,3; 3 A Ohm: 1; 10; 100; 1000; 10000 Ohm. Transistor control: npn and pnp, Ik and Ib.
- Net weight (2.2 lb = 1 kg)
- 0.606 kg / 1 lb 5.4 oz (1.335 lb)
- Price in first year of sale
- 39.00 Rub
- Source of data
- -- Collector info (Sammler)
- Author
- Model page created by Sándor Selyem-Tóth. See "Data change" for further contributors.
