Vol'tmetr-Universal'nyj - Вольтметр-Универсальный (Universelles-Voltmeter) V7-17 - В7-17 (B7-17)

• Country
• Soviet Union

• Manufacturer / Brand
• Unknown - CUSTOM BUILT: Soviet Union

• Year
• 1976

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 117991

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 2

• Valves / Tubes
• 6Н2П 6Н3П

• Number of Transistors
• 2

• Semiconductors

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Metal case

• from Radiomuseum.org
• Model: Vol'tmetr-Universal'nyj - Вольтметр-Универсальный V7-17 - В7-17 - Unknown - CUSTOM BUILT: Soviet

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 200 x 220 x 140 mm / 7.9 x 8.7 x 5.5 inch

• Notes
• Universelles Voltmeter mit aktivem Tastkopf mit Mini-Keramik-Dioden-Röhre 6d24n; Transistoren im Netzteil: P214, MP42P.
  Messbereiche: 30 mV bis 1000 V DC; 200 mV bis 300 V AC bei 1 kHz bis 1000 MHz; R_i = 10 MOhm bis 1000 MOhm.

• Net weight (2.2 lb = 1 kg)
• 0.8 kg / 1 lb 12.2 oz (1.762 lb)

• Mentioned in
• -- Original-techn. papers.

• Author
• Model page created by Dieter Sternal. See "Data change" for further contributors.
