• Country
• People's Republic of China

• Manufacturer / Brand
• Unknown - CUSTOM BUILT: China

• Year
• 2022 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 343353

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• DSP, Digital Signal Processor

• Wave bands
• Broadcast, more than 2 SW bands plus FM or UHF.

• Details
• Radio with other functions

• Power type and voltage
• Storage and/or dry batteries / Li-Ion: 3,6 / AAA: 3 x 1.5 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Emergency Radio Model No. 376 - Unknown - CUSTOM BUILT: China

• Shape
• Very small Portable or Pocket-Set (Handheld) < 8 inch.

• Dimensions (WHD)
• 150 x 75 x 50 mm / 5.9 x 3 x 2 inch

• Notes

• Stromversorgung über Li-Ionen-Akku und/oder 3x AAA. Aufladen mit Kurbel, USB oder Solarzelle. Eingebaute Taschenlampe, Leselampe und Powerbank-Funktion.

  9 Kurzwellenbereiche, durchgängig von 3,2 - 22 MHz

  Eine Minute Kurbeln ergibt fünf Minuten Radiobetrieb. Eine volle Akkuladung reicht etwa 40 bis 50 Stunden.

• Author
• Model page created by Martin Steyer. See "Data change" for further contributors.
