- Country
- United States of America (USA)
- Manufacturer / Brand
- Apex Electric, Pool; Chicago; US Radio & Television Corp.; Marion; (US Radio&Refrigeration)
- Year
- 1929
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 160007
-
- alternative name: Apex Electric Mfg. || Case Electric || Melrose || United States Radio & T
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 7
- Main principle
- TRF (Tuned-Radio-Frequency but use of regeneration unknown); Screengrid 1926-1935
- Power type and voltage
- Alternating Current supply (AC)
- from Radiomuseum.org
- Model: Apex 14 - Apex Electric, Pool; Chicago;
- Notes
- Push-pull af output stage.
- Circuit diagram reference
- Rider's Perpetual, Volume 1 = 1931/1934 (for 1919-1931)
- Author
- Model page created by Hans-Joachim Korn † 16.11.15. See "Data change" for further contributors.
