• Country
• Hungary

• Manufacturer / Brand
• Vadasztoltenygyar, VTRGy, see Videoton

• Year
• 1968–1972 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 319319

• Number of Tubes
• 6

• Valves / Tubes
• ECC85 EBF89 ECH81 EL86 EM87 EL86

• Number of Transistors
• 2

• Semiconductors
• OA1172 OA1172

• Main principle
• Superheterodyne (common); ZF/IF 460/10700 kHz

• Wave bands
• Broadcast, Long Wave, Short Wave plus FM or UHF.

• Details
• Record Player (perh.Changer)

• Power type and voltage
• Alternating Current supply (AC) / 110; 127; 150; 220; 240 Volt

• Loudspeaker
• 4 Loudspeakers

• Power out
• 2 W (unknown quality)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Radiogram XR5930-B117 - Vadasztoltenygyar, VTRGy, see

• Shape
• Console, Lowboy (legs < 50 %).

• Dimensions (WHD)
• 1470 x 650 x 400 mm / 57.9 x 25.6 x 15.7 inch

• Notes

• With auto turntable, Garrard 1025
  FM: 87.5 - 104 MHz

  Height of console legs: 27 cm

• Mentioned in
• -- Collector info (Sammler)

• Author
• Model page created by Sándor Perneky. See "Data change" for further contributors.
