Ten Transistor PTR-100

Valiant Watch Ltd.; New York (NY)

Data
Forum
Pictures
Collections

  • Year
  • 1965 ??
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 144412

 Technical Specifications

  • Number of Transistors
  • 10
  • Semiconductors
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Broadcast only (MW).
  • Power type and voltage
  • Dry Batteries / 1 x 9 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Ten Transistor PTR-100 - Valiant Watch Ltd.; New York
  • Shape
  • Very small Portable or Pocket-Set (Handheld) < 8 inch.
  • Dimensions (WHD)
  • 5.5 x 3 x 1 inch / 140 x 76 x 25 mm
  • Notes

  • Valiant Ten Transistor, PTR-100;
    Dial window, earphones jack, sold with suitable black leather carrying case.  Not similar to the several "Valiant 10 Transistor" but most similar to Candle PTR-100, Ross 10, Walker 10. Externally similar to Candle PTR-63.



    Made in Japan

  • Source of data
  • -- Collector info (Sammler)
  • Author
  • Model page created by a member from A. See "Data change" for further contributors.
