Vefsuper M517 EL11 tube series
VEF Radio Works (Valst Elektrotechniska Fabrika, ВЕФ); Riga
- Country
- Latvia (Latvia, Riga)
- Manufacturer / Brand
- VEF Radio Works (Valst Elektrotechniska Fabrika, ВЕФ); Riga
- Year
- 1942 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 92769
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common); ZF/IF 128 kHz
- Tuned circuits
- 7 AM circuit(s)
- Wave bands
- Broadcast, Long Wave and Short Wave.
- Power type and voltage
- Alternating Current supply (AC) / 120/220 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 16 cm = 6.3 inch
- Power out
- 2.5 W (unknown quality)
- Material
- Wooden case
- from Radiomuseum.org
- Model: Vefsuper M517 [EL11 tube series] - VEF Radio Works Valst
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 480 x 310 x 235 mm / 18.9 x 12.2 x 9.3 inch
- Notes
- Within German occupation of 1941-44 factory VEF was under the control of firm AEG and referred to AEG Ostlandwerk. At a factory many from issued before models have been advanced under the tubes applied by this and other German firms. At this device as it is a lot of variants of design of the case.
- Net weight (2.2 lb = 1 kg)
- 8.5 kg / 18 lb 11.6 oz (18.722 lb)
- Source of data
- - - Data from my own collection
