• Country
• Latvia (Latvia, Riga)

• Manufacturer / Brand
• VEF Radio Works (Valst Elektrotechniska Fabrika, ВЕФ); Riga

• Year
• 1932/1933

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 137886

• Number of Tubes
• 3

• Valves / Tubes
• 227 47 80 or 1-V

• Main principle
• TRF with regeneration; 1 AF stage(s)

• Tuned circuits
• 1 AM circuit(s)

• Wave bands
• Broadcast (MW) and Long Wave.

• Power type and voltage
• Alternating Current supply (AC) / 120/220 Volt

• Loudspeaker
• Permanent or electro-dynamic (moving coil), system not known yet. / Ø 20 cm = 7.9 inch

• Material
• Wooden case

• from Radiomuseum.org
• Model: VEFAR 2MD - VEF Radio Works Valst

• Shape
• Tablemodel, high profile (upright - NOT Cathedral nor decorative).

• Notes
• More tube variants.

• Source of data
• - - Data from my own collection

• Other Models

• Here you find 139 models, 136 with images and 76 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
  All listed radios etc. from VEF Radio Works (Valst Elektrotechniska Fabrika, ВЕФ); Riga
