VEFSuper M507N
VEF Radio Works (Valst Elektrotechniska Fabrika, ВЕФ); Riga
- Country
- Latvia (Latvia, Riga)
- Manufacturer / Brand
- VEF Radio Works (Valst Elektrotechniska Fabrika, ВЕФ); Riga
- Year
- 1940
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 223924
Chassis-Unterseite vor der Aufarbeitung
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common); ZF/IF 132 kHz
- Tuned circuits
- 7 AM circuit(s)
- Wave bands
- Broadcast, Long Wave and 2 x Short Wave.
- Power type and voltage
- Alternating Current supply (AC) / 120-240 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
- Material
- Wooden case
- from Radiomuseum.org
- Model: VEFSuper M507N - VEF Radio Works Valst
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 478 x 310 x 217 mm / 18.8 x 12.2 x 8.5 inch
- Notes
- This is an export variant of VEFSuper M507 with additional tropic (sea wheather, fishery) bands 70-200m.
- Net weight (2.2 lb = 1 kg)
- 9.3 kg / 20 lb 7.8 oz (20.485 lb)
- Author
- Model page created by Sergey Kashekhlebov. See "Data change" for further contributors.
