Sonata {Соната} 201

• Country
• Soviet Union

• Manufacturer / Brand
• Leningrad NOVATOR Works

• Year
• 1972–1975 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 99090

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 10

• Semiconductors
• П423 П423 П422 П422 П422 МП40 МП40 МП40 ГТ402 ГТ402 Д9

• Main principle
• Superheterodyne (common); ZF/IF 465 kHz

• Tuned circuits
• 8 AM circuit(s)

• Wave bands
• Broadcast, Long Wave and more than two Short Wave bands.

• Power type and voltage
• Dry Batteries / 2 × 4,5 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Power out
• 0.3 W (unknown quality)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Sonata {Соната} 201 - Leningrad NOVATOR Works

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 252 x 143 x 78 mm / 9.9 x 5.6 x 3.1 inch

• Notes

• Coverage LW, MW and 4× SW.

• Net weight (2.2 lb = 1 kg)
• 2 kg / 4 lb 6.5 oz (4.405 lb)
