• Country
• Spain

• Manufacturer / Brand
• Vica (Talleres), Capdevila; Barcelona

• Year
• 1950 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 197033

• Number of Tubes
• 5

• Valves / Tubes
• ECH4 EF9 EBC3 EL3 AZ1

• Main principle
• Superheterodyne (common); ZF/IF 470 kHz

• Wave bands
• Broadcast and Short Wave (SW).

• Power type and voltage
• Alternating Current supply (AC) / 125 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 16 cm = 6.3 inch

• Power out
• 4.5 W (unknown quality)

• Material
• Wooden case

• from Radiomuseum.org
• Model: 163 [ECH4] - Vica Talleres, Capdevila;

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 410 x 270 x 215 mm / 16.1 x 10.6 x 8.5 inch

• Notes

• Véase también Vica 163 [ECH4-EBL1].

• Author
• Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
