• Country
• Spain

• Manufacturer / Brand
• Vica (Talleres), Capdevila; Barcelona

• Year
• 1960 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 218433

• Number of Tubes
• 5

• Valves / Tubes
• UCC85 UCH81 UF89 UABC80 UL84

• Main principle
• Superheterodyne (common); ZF/IF ? / 10700 kHz

• Wave bands
• Broadcast, Short Wave plus FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 125; 220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5 inch = 12.7 cm

• Material
• Wooden case

• from Radiomuseum.org
• Model: 333 - Vica Talleres, Capdevila;

• Shape
• Tablemodel with Push Buttons.

• Dimensions (WHD)
• 470 x 160 x 100 mm / 18.5 x 6.3 x 3.9 inch

• Notes
• Solid state rectifier.

• Author
• Model page created by Jordi Duran. See "Data change" for further contributors.
