103-G
Vilor-Radio; Valencia
- Country
- Spain
- Manufacturer / Brand
- Vilor-Radio; Valencia
- Year
- 1956 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 287505
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common); ZF/IF 470 kHz; 2 AF stage(s)
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast, Short Wave(s) and Police.
- Power type and voltage
- Alternating Current supply (AC) / 110; 125 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 15 cm = 5.9 inch
- Power out
- 3.5 W (unknown quality)
- Material
- Wooden case
- from Radiomuseum.org
- Model: 103-G - Vilor-Radio; Valencia
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 450 x 290 x 225 mm / 17.7 x 11.4 x 8.9 inch
- Notes
-
En onda pesquera, lleva en el dial los puertos de Valencia.
- Net weight (2.2 lb = 1 kg)
- 4.4 kg / 9 lb 11.1 oz (9.692 lb)
- Price in first year of sale
- 2,995.00 ESP
- Author
- Model page created by Carlos Saavedra. See "Data change" for further contributors.
